♦Adopt imported compressor with stable performance, durability and low noise.
♦It is equipped with an Italian thermostat, which can accurately control the water temperature between +5°C and +35°C, and control the temperature difference within the range of soil 1°C.
♦ Unique design of condenser and evaporator, excellent heat exchange effect.
♦ Equipped with stainless steel heat preservation water tank, easy to clean.
♦ The temperature of ultra-low temperature chiller can reach below -15°C.
♦Air-cooled cooling air is inhaled from the peripheral side of the fuselage, and the top discharge effect is better, no cooling tower is required, and the installation is simple.
規格表：Specification
型號Model | 冷凍能力 | 輸出功率 | 冷凍管徑 | 泵浦功率 | 冷凍流量 | 水箱容量 | 外形尺寸 | 重量 |
Refrigera. Capacity Output Power Refrigera.ID | Pump Power | Refrigera. Flow Tank Capacity | Size | Weight |
| BTU/KCAL | KW | PT | KW | L/min | L | mm | Kg |
TCO-02A | 16000/4032 | 1.5 | 3/4"x1 | 0.75 | 110 | 60 | 830x470x930 | 75 |
TCO-05A | 51200/12900 | 3.7 | 3/4"x1 | 0.75 | 110 | 80 | 1225x650x1465 | 120 |
TCO-10A | 102400/25800 | 7.5 | 2" | 1.5 | 200 | 150 | 1530x760x1650 | 380 |
TC0-15A | 116050/29240 | 9 | 2.5" | 2.2 | 350 | 190 | 1630x850x1910 | 450 |
TCO-15AD | 163800/41280 | 11 | 2.5" | 2.2 | 350 | 240 | 1750x1400x1730 | 500 |
TCO-20A | 204100/51433 | 15 | 2.5" | 2.2 | 350 | 290 | 1850x1300x2000 | 800 |
TCO-30A | 232100/58490 | 18 | 2.5" | 3.7 | 600 | 340 | 2000x1450x2100 | 900 |
TCO-30AD | 314000/79100 | 22 | 3" | 3.7 | 600 | 500 | 2800x1350x2000 | 1100 |
TCO-36A | 365400/92070 | 27 | 3" | 5.5 | 900 | 500 | 2800x1450x2100 | 1300 |
TCO-40A | 406000/102300 | 34 | 3" | 5.5 | 900 | 650 | 2500x1200x1720 | 1600 |
TCO-48A | 487200/122760 | 36 | 3" | 5.5 | 900 | 650 | 2700x1650x2200 | 1800 |
★商品規格若有變更，恕不另行通知：We reserve the right to change specifications without prior notice.
